a:350-650nm
b:650-1050nm
c:1050-1580nm
| 编号(no.) | 焦距(efl) | 直径(dia) | r1=r2 | 中心厚(tc) | 边厚(te) | 后焦距(bfl) |
| 11b1157r | 10.00 | 6.00 | 9.88 | 2.40 | 1.50 | 9.17 |
| 11b1406r | 12.00 | 6.00 | 11.96 | 2.30 | 1.50 | 11.22 |
| 11b1987r | 15.00 | 6.00 | 15.09 | 2.10 | 1.50 | 14.29 |
| 11b1198r | 30.00 | 6.00 | 30.60 | 1.80 | 1.50 | 29.40 |
| 11b1494r | 12.00 | 9.00 | 11.72 | 3.60 | 1.80 | 10.75 |
| 11b1212r | 20.00 | 9.00 | 20.12 | 2.80 | 1.80 | 19.05 |
| 11b1092r | 15.00 | 12.70 | 14.61 | 4.70 | 1.80 | 13.36 |
| 11b1450r | 20.00 | 12.70 | 19.92 | 3.90 | 1.80 | 18.67 |
| 11b1014r | 25.00 | 12.70 | 25.16 | 3.40 | 1.80 | 23.85 |
| 11b1258r | 30.00 | 12.70 | 30.37 | 3.10 | 1.80 | 28.96 |
| 11b1378r | 40.00 | 12.70 | 40.73 | 2.80 | 1.80 | 39.07 |
| 11b1844r | 50.00 | 12.70 | 51.06 | 2.60 | 1.80 | 49.13 |
| 11b1187r | 100.00 | 12.70 | 102.64 | 2.20 | 1.80 | 99.27 |
| 11b1761r | 25.40 | 25.40 | 24.53 | 9.00 | 1.90 | 22.23 |
| 编号(no.) | 焦距(efl) | 直径(dia) | r1=r2 | 中心厚(tc) | 边厚(te) | 后焦距(bfl) |
| 11b1757r | 30.00 | 25.40 | 29.54 | 7.70 | 2.00 | 27.34 |
| 11b1811r | 35.00 | 25.40 | 34.86 | 6.80 | 2.20 | 32.68 |
| 11b1027r | 40.00 | 25.40 | 40.14 | 6.10 | 2.00 | 37.93 |
| 11b1471r | 50.00 | 25.40 | 50.61 | 5.20 | 2.00 | 48.25 |
| 11b1596r | 60.00 | 25.40 | 61.00 | 4.70 | 2.00 | 58.43 |
| 11b1901r | 75.00 | 25.40 | 76.56 | 4.10 | 2.00 | 73.63 |
| 11b1676r | 100.00 | 25.40 | 102.40 | 3.60 | 2.00 | 98.81 |
| 11b1904r | 125.00 | 25.40 | 128.21 | 3.30 | 2.00 | 123.91 |
| 11b1437r | 150.00 | 25.40 | 154.00 | 3.10 | 2.00 | 148.97 |
| 11b1294r | 175.00 | 25.40 | 179.79 | 2.90 | 2.00 | 174.04 |
| 11b1945r | 200.00 | 25.40 | 205.56 | 2.80 | 2.00 | 199.07 |
| 11b1056r | 250.00 | 25.40 | 257.10 | 2.60 | 2.00 | 249.14 |
| 11b1779r | 300.00 | 25.40 | 308.63 | 2.50 | 2.00 | 299.17 |
| 11b1391r | 400.00 | 25.40 | 411.66 | 2.40 | 2.00 | 399.21 |
| 11b1869r | 500.00 | 25.40 | 514.70 | 2.30 | 2.00 | 499.24 |
| 编号(no.) | 焦距(efl) | 直径(dia) | r1=r2 | 中心厚(tc) | 边厚(te) | 后焦距(bfl) |
| 11b1475r | 750.00 | 25.40 | 772.26 | 2.20 | 2.00 | 749.27 |
| 11b1409r | 1000.00 | 25.40 | 1029.81 | 2.20 | 2.00 | 999.27 |
| 11b1723r | 60.00 | 50.80 | 59.26 | 14.40 | 3.00 | 55.04 |
| 11b1309r | 75.00 | 50.80 | 75.20 | 11.80 | 3.00 | 71.00 |
| 11b1630r | 100.00 | 50.80 | 101.38 | 9.50 | 3.00 | 96.81 |
| 11b1106r | 125.00 | 50.80 | 127.38 | 8.10 | 3.00 | 122.30 |
| 11b1374r | 150.00 | 50.80 | 153.29 | 7.20 | 3.00 | 147.60 |
| 11b1607r | 175.00 | 50.80 | 179.15 | 6.60 | 3.00 | 172.81 |
| 11b1199r | 200.00 | 50.80 | 204.98 | 6.20 | 3.00 | 197.94 |
| 11b1889r | 250.00 | 50.80 | 256.61 | 5.50 | 3.00 | 248.18 |
| 11b1917r | 300.00 | 50.80 | 308.19 | 5.10 | 3.00 | 298.31 |
| 11b1862r | 400.00 | 50.80 | 411.29 | 4.60 | 3.00 | 398.48 |
| 11b1909r | 500.00 | 50.80 | 514.36 | 4.30 | 3.00 | 498.58 |
| 11b1274r | 750.00 | 50.80 | 771.99 | 3.80 | 3.00 | 748.75 |
| 11b1859r | 1000.00 | 50.80 | 1029.57 | 3.60 | 3.00 | 998.81 |
