llq223-30mw
llq223-30mw全固态223nm的紫外激光器广泛用于紫外光固化，微电子，光盘雕刻，激光医疗，科学实验等
wavelength (nm)223.5± 1
operating modeelectro-optic q-switched
average power (w)1~30mw (30mw@ 10khz)
average power (w) = single pulse energy (mj) * rep. rate (khz)
single pulse energy ( µj)1~3 (3μj @ 10khz)
rep. rate (khz)10
pulse duration (ns)~4 @ 10khz
peak power (kw)~0.75 (0.75kw@ 10khz)
ave power stability (over 4 hours)<3%, <5%
warm-up time (minutes)< 10
beam divergence, full angle (mrad)<5
beam diameter at the aperture ( 1/e2,mm)<8
beam height from base plate (mm)68.5
cooled methodair cooled
operating temperature (c)10~35
power supply (220/ 110vac)psu-aom (3u)
expected lifetime (hours)10000
warranty period1 year
